PS & Protection Assembly

PS & Protection Assembly
PS & Protection Assembly
₱557.00
  • Stock: In Stock
  • Product Code: 77009134
  • Weight: 0.00g
  • Product ID: 10

Two galvanically isolated bipolar rectifier-filter circuit with speaker protection circuitry that can be used with a wide range of DIY audio amplifier projects. All rectifier sections are capacitor shunted to minimize potential interference with the sensitive parts of your audio circuit


Wiring :

  • Sample Application


Specifications :
Power Input36VAC ~ 0VAC ~ 36VAC & 12VAC ~ 0VAC ~ 12VAC
Output
+36VDC , -36VDC & +12VDC , -12VDC
Operating Current
7A limit


Downloads :
Schematic DiagramDownload
Sample Wiring and Connection Diagram
Download
BlogLink
Audio Interfacing Application NotesDownload
