Updated: 5/17/21

SERVO MOTORS SECTIONS:

P3 : SERVO 1
P4 : SERVO 2
P5 : SERVO 3
P6 : SERVO 4

PROPER UPLOADING:

Press and Hold the SYS RST (SW3) then switch ON the Power (SW1)
and Click Upload. Release SYS RST when done.

PBOT 2018 FUNCTION REVIEW:

  • Set Servo number and position in degrees from 0 to 180.
  • Servo Controls

PBOT.SERVO(whichservo,pulsewidth);

where:
whichservo = 1 to 4, ignore other values
pulsewidth = 0 to 180 (degrees)
           - value less than 500 stops the SERVO PWM generator
           - the pulsewidth converted to degrees from 0 to 180 (default)

Ex.:

GET STARTED:

  1. Setting Up your Arduino IDE with ArduBlocks and the eGizmo PBOT2018 Library. (Read Here)
  2.  In ArduBlock, using PBOT 2018,

START WITH ADDING A BLOCK “PBOT BEGIN”

Adding PBOT BEGIN block – settting up the eGizmo_PBOT2018, Wire library and turn ON all the motors.

FOR SERVO BLOCKS

Double Click the block 1 to change the servo number also the 90 degrees to change it.

Upload to Arduino. This will shown on the IDE.

 ”

YOU NEED TO FOLLOW THE EXTERNAL POWER SUPPLY FOR SERVO MOTORS.

Sample connection for Servo Supply you need another supply +6V for +V of servo channels.

Sample connection with 7.2v Ni-MH battery. Put a jumper for servo supply

  • SERVO SWEEP.ino

/**********************************************
* e-Gizmo PBOT2018 Controller - SERVO_SWEEP.ino
*
* This is for SERVO sample sketch
* to sweeps the shaft back and forth
* across 180 degrees.
*
* SERVO Control
* ex. PBOT.SERVO(whichSERVO,pulsewidth);
* where:
* whichservo = 1 to 4 ,ignore other values
* pulsewidth = 0 to 180 (degrees)
* - value less than 500 stops the SERVO PWM generator
* - the pulsewidth converted to degrees from 0 to 180 (default)
*
* Codes by
* e-Gizmo Mechatronix Central
* http://www.e-gizmo.com
* June 5,2018
************************************************/
#include "eGizmo_PBOT2018.h"
#include <Wire.h>
eGizmo_PBOT2018 PBOT; // Create PBOT object to control a SERVO
int POS = 0; //servo start position
void setup() {
Wire.begin();
PBOT.BEGIN();
}
void loop() {
for(POS = 10; POS < 170; POS += 1) // goes from 00 degrees to 170 degrees
{ // in steps of 1 degree
PBOT.SERVO(1, POS); // tell servo to go to position in variable 'pos'
PBOT.SERVO(2, POS);
PBOT.SERVO(3, POS);
PBOT.SERVO(4, POS);
delay(15);
// waits 15ms for the servo to reach the position
}
for(POS = 170; POS>=10; POS-=1) // goes from 170 degrees to 10 degrees
{
PBOT.SERVO(1, POS); // tell servo to go to position in variable 'pos'
PBOT.SERVO(2, POS);
PBOT.SERVO(3, POS);
PBOT.SERVO(4, POS);
delay(15); // waits 15ms for the servo to reach the position
}
}
view rawSERVO_SWEEP.ino hosted with ? by GitHub
