Airpax 67L120 120C T0-220 Bimetal Disc Thermostat N.C.

Tags: Bimetal , Resetabble Fuse , Thermal Fuse , Fuse

Description
Reviews

The Airpax™ 6700 series is a RoHS compliant, positive snap action, single pole / single throw, sub-miniature bimetallic thermostat which provides accurate and reliable sensing and switching in a single device.

- Normally Close. Open on rise.

Cutoff Temperature: 120C +/-5C
Reset Temperature: 85C
Contact Ratings:
Current: 0.5A @ 48VDC
Duty: >20,000 cycles @ 48V 0.5A, >100,000 cycles @ 5V 1mA
Resistance: 0.05R
Contact Material: Gold-plated or overlay, silver crossbar

Package/Image: airpax
