Lelon 330uF 10V 105C Organic Conductive Polymer Capacitor OCV Series

Tags: capacitor , tantalum capacitor , smd tantalum , solid polymer , conductive polymer , low esr

Description
Reviews

Lelon Organic Conductive Polymer Capacitors SMD.

Ultra low ESR with large permissible ripple current

Manufacturer Part No: OV-331M1ATR-0812
Capacitance: 330uF +/-20%
Working Voltage: 10VDC
Category Temperature Range: -55C to +105C
Dissipation Factor: 0.15@120Hz
Ripple Current: 4420mA @ 100kHz +105C
Impedance: 0.014 ohms
Dimensions: d8x 12mm

Markings may vary from what is shown in the image.

Prices and stock availability subject to change without prior notice. If you want this product but it indicates it is not in stock, chat us or simply add it to your cart anyway. Our staff will contact you to inform if we can/cannot provide the item in your order.
