CapXon 2200uF/25V KF series 105C Low ESR capacitor

Tags: capacitor , electrolytic , electrolytic capacitor

Description
Reviews

CapXon (Taiwan) KF Series Low Impedance Capacitor

Capacitance: 2200uF +/-20%
Working Voltage: 25VDC
Max. Impedance @100KHz: 0.035R
Dissipation Factor: 12%max at 120Hz
Load Life: 2000-5000 Hours at 105C
Ripple Current: 2650mA @ 105C
Dimensions: d12 x h40 mm
Lead Spacing: 5mm

Prices and stock availability subject to change without prior notice. If you want this product but it indicates it is not in stock, chat us or simply add it to your cart anyway. Our staff will contact you to inform if we can/cannot provide the item in your order.
