NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA

NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
New
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
NEC EC2-5NJ 5V 2A DPDT Compact Relay UL,CSA
₱40.00
  • Stock: In Stock
  • Product Code: 130800033
  • Weight: 0.00g
  • Product ID: 49996
Tags: relay

NEC EC2-5NJ Relay.
Made in Japan

Contact Rating:
Maximum Switching Power: 125VA
Maximum Switching Voltage: 220VDC/250VAC
Maximum Switching Current: 2A
Maximum Carrying Current: 2A
Intial Contact Resistance: 0.05R
Contact Material: Silver Alloy with Gold Alloy overlay
Operate Time: 2ms
Release Time: 1ms
Running Specifications: >1million operations @ 0.1A load

Coil Specifications
Nominal Coil Voltage: 5VDC
Must Operate Voltage: 3.75V
Must Release Voltage: 0.5V
Coil Resistance: 178 ohms

Safety Listing: UL, CSA
